Interdomain traffic engineering with MPLS


During the last years, MultiProtocol Label Switching (MPLS) has been deployed by most large Service Providers (SP). The main driver for MPLS deployment is the ability to provide new services with stringent Service Level Agreements (SLAs) such as layer-2 and layer-3 Virtual Private Networks (VPNs) as well as Voice and Video over IP. Most of these services are already deployed inside single SP networks. However, customers now require world-wide VPN and VoIP services. Therefore, SPs need to collaborate to offer these services across multiple SP networks. Inside a single SP network, each node usually knows the complete topology of the network with the load and delay of all the links. Based on this information, each router is able to compute constrained paths toward any other router inside the SP network. Then, it can establish a connection and reserve resources along the computed path with the Resource reSerVation Protocol (RSVP-TE). However, when services with stringent requirements must cross multiple SP networks the computation of the path becomes a problem. Routers in different SP networks exchange routing information by using the Border Gateway Protocol (BGP). BGP provides reachability information. It does not distribute complete topology, delay and bandwidth information. One way to provide guaranteed services crossing different SPs is to delegate the computation of the paths to a Path Computation Element (PCE) that learns the topology of the different SPs. However, this requires that SPs reveal information that they usually consider confidential, their topology. In this thesis, we perform active measurements to show the difficulty to engineer the interdomain traffic with BGP. MPLS together with RSVP-TE provide much more control on the traffic. We define extensions to RSVP-TE for the protection of inter-AS MPLS paths. The aim is to be able to provide the same service guarantees as inside a domain while keeping the internal topology of SPs confidential, as required by SPs. We propose and evaluate distributed techniques relying on PCEs for the computation of interdomain constrained paths respecting the latter confidentiality requirement.

Cristel Pelsser
Cristel Pelsser
Critical embedded systems, Computer networking, Researcher, Professor

The focus of my research is on network operations, routing, Internet measurements, protocols and security.
